Mortar and Pestle Porcelain
This is used to pulverize/mash/grind and mixes materials in a mortar
using a pestle to demonstrate how particle size affects solubility and
the rate of chemical reaction.
Decreasing the size of the particles increases the rate of dissolving
and speeds up the rate of reaction because the surface area of the
reactant has been increased.
A. Mortar:-
Shape of mortar : Bowl shape, with wide mouth , and with deeply molded, smooth rounded bottom
Material for mortar and pestle: Porcelain with the following dimensions:
a) Outside diameter : 130 mm ± 1 mm
b) Depth : 65 mm
c) Flat bottom : 87 mm
Capacity: 150 mL
With pouring lip
With unglazed grinding surface (interior) and uniformly glazed exterior
B. Pestle:-
Shape of pestle: Cylindrical a with bulbous bottom with the following dimensions:
a) Length range: 133-135 mm and
b) Diameter range : 28 - 30 mm dia at its widest point. Tender product as per DEPED Guidelines.
